Basic fuel pump
for fuel line, 145 l/h @ 3 bar. Diameter 52 mm. Connections: Inlet
12mm for hose, outlet 8 mm for hose, electrical (- / +)
M5/M6. Protection caps and terminals included.
|
0580464070 |
|
|
Pump for in-tank
assembly. 102 l/h @ 6.5 bar. Diameter 60 mm.
Connections: Inlet open base with
steel net, outlet M10X1.0 , electrical (- / +) M5/M6.
Non-return valve can be changed. |
0580254040 |
|
|
3 bar high flow pump, 195 l/h @3 bar. Diameter 60 mm
Connections: Inlet M14X1.5 inside thread, outlet M12X1.5
inside thread, electrical (- / +) M5/M6. Non- return valve can be
removed.
|
0580254979 |
|
|
High power pump for fuel line or in-tank
assembly. Built-in filter. Diameter 60 mm.
Connections: Inlet M18X1.5 inside
thread, outlet M12X1.5 (use 12 mm banjo, seals and cap
nut 2915142018), electrical
(- / +) M5/M6.
|
172 l @7 bar
>200 l@8 bar |
0580254044
B261205413 |
|
|
5 bar "universal" fuel pump.
Diameter 60 mm. Connections: Inlet 12mm for hose, outlet
M12X1.5 (use 12 mm banjo, seals and cap nut 2915142018),
electrical (- /
+) M5/M6. Protection caps and terminals included.
|
168 l @ 5 bar
200 l @ 5 bar |
0580254909
0580254053 |
|
|
Alternate non-return valve for Bosch pumps
with M12X1.5 thread.
Thread on the pump side M12X1.5 and
pressure connection with M16X1.5 (cone). Suitable hose
connectors for this non-return valve are MKS-C013 with
MKS-C035. For pumps ...053, ...909, ...044 etc.
|
1587010534 |
|
|
High flow pre-delivery pump for intank
assembly. Filter included. Manufacturer VDO.
|
E22057013 |
|
|
Cap nut for
Bosch fuel pumps with M12x1,5 mm thread. For pumps:
0580254909, 0580254053, 0580254044 etc.
Banjos and other hose connectors are
located here
|
2915142018 |
|
|
2,5 bar fuel pressure
regulator with vacuum connection. 2 pcs connectors for 8
mm hoses.
Variable version also available,
pressure range from 1,5 up to 4,5 bar.
|
basic
variable
|
0280160221
0280160221V |
|
|
3 bar fuel pressure
regulator with vacuum connection. 2 pcs pressure
connection and one connection for return. Fuel connections
8 mm.
Adjustable version also available,
pressure range from 1,5 up to 4,5 bar.
|
basic
variable |
0280160202
0280160202V
|
|
|
3 bar fuel pressure
regulator with vacuum connection. Fuel connectors with
M14X1.5 with 60 cone.
Adjustable version also available,
pressure range from 1,5 up to 4,5 bar
|
basic
variable |
0280160234
0280160234V
|
|
|
Adjustable fuel pressure regulator with
vacuum connection. High flow model with 2 pressure
connection (M16X1.5 with 60 cone). Return connection for 8
mm hose.
Adjustable version, pressure range
from 2,5 up to 7 bar.
|
variable |
VFPR-4 |
|
|
Fuel pressure
regulator with vacuum connection. Pressure connection
directly to the fuel rail with O-ring. Return connection
for 8 mm hose.
Adjustable versions also available,
pressure ranges from 1,5 up to 6,5 bar.
|
2,5 bar
3,0 bar
3,8 bar |
0280160225
0280160226
0280160263 |
|
|
DIY kit for modifiying a small
"basic"
Bosch pressure regulator to adjustable version. Kit includes all the
parts needed.
After the modification, vacuum/ boost
connection is still present. Pressure range from 2 bar up
to 5 bar.
|
VFPR-SET-1
|
|
|
DIY kit for modifiying a big
"basic" Bosch pressure regulator to adjustable version. Kit includes all the parts needed. Only basic
hand tools needed.
After the modification, vacuum/ boost
connection is still present. Pressure range from 1,5 bar
up to 4,5 bar
|
VFPR-SET-2
|
|
|
"Small" fuel pressure regulator
with vacuum connection. Assembly directly to the fuel
rail.
With the VFPR-SET-1
small regulator can be modified for adjustable version.
|
3,5 bar
3,8 bar
4,0 bar |
0280160504
0280160387
0280160575 |
|
|
New and
updated data is available at our web shop www.finjector.com
(also in English)
|
|
|
|
|
|
|
|
|
|
|
